Oase AquaMax Eco Expert Pond Pump
Large waterfalls and long streams
Swimming ponds and natural pools (12 V)
Owners replacing a tired pump with an efficient one
Oase · Pond Pumps
The owner's insights on the AquaMax Eco Expert Pond Pump
The pump is the one part of a pond that never gets a day off. The AquaMax Eco Expert is the high-output end of the Oase range, built for koi ponds running a drum or gravity filter. It also suits waterfalls with real height. Flow runs from 21,000 to 44,000 litres an hour on mains power.
What sets it apart is control. Flow is adjusted electronically, so you can turn it down on a still evening or up when the filter needs it. Oase say the Seasonal Flow Control function saves up to 30% more energy, which matters on a pump that runs around the clock.
It is more pump than a small garden pond needs. A fish pond of a few thousand litres is better served by the AquaMax Eco Premium or Classic, at a fraction of the price. The 12 V models are the other exception: they exist for swimming ponds and natural pools, where low voltage is the safer choice.
Size it to the filter first, then allow for the lift. Every metre the water climbs to a waterfall or filter inlet reduces the flow you actually get. Send us the filter model, the height and the pipe run before you order. We will match the pump to it.
Why you'll love the AquaMax Eco Expert Pond Pump
Turn the flow up or down
Electronic adjustment lets you match output to the filter, the season and the look of the waterfall.
Lower running costs
Seasonal Flow Control can save up to 30% more energy on a pump that runs day and night.
Protected against dry running
Environmental Function Control guards the pump if the water drops or the intake blocks.
Moves the mess to the filter
Solids up to 11 mm pass through, so leaves and fish waste reach the filter instead of clogging the pump.
In the pond or out of it
Run it submerged or dry installed in a pump chamber, where its quiet running suits a spot near the house.
Safe where people swim
The 12 V models run on low voltage for swimming ponds and natural pools, including saltwater.
Why you should consider an Oase pond pump
Oase is a German company that has engineered pond and water equipment since 1949. The AquaMax Eco Expert is made in Germany. In Australia it is supplied by Aquatec Equipment, part of the Oase Group. Order through My Acre and we will beat any genuine like-for-like price you find elsewhere. If a warranty question ever comes up, you are calling us directly, not an overseas call centre.
Talk it through before you order
Tell us the filter, the height the water lifts and the length of the pipe run. We will pick the flow that suits it. If a smaller pump will do, we will say so.
Call todayWork out the flow and head you need
Step one: the flow your system asks for
| The job | Flow you need | How to get the number |
|---|---|---|
| A filter | The whole pond once an hour | Pond volume in litres becomes litres per hour. A 25,000 L pond wants 25,000 l/h. |
| A koi system on a drum or flow-through filter | Match the filter rating | Read the filter maximum, never exceed it |
| A long stream or a big waterfall | By the width of the lip | Our rule of thumb: about 1,500 l/h per 10 cm of weir width |
This range starts at 19,300 l/h. If your answer is under about 20,000 l/h, the standard AquaMax Eco range is the better buy.
Step two: head, then match the model
- 1. Measure the vertical rise from the water surface to the outlet, in metres.
- 2. Add about 10% of the hose run as friction. A 20 m run adds roughly 2 m of head.
- 3. Compare that total to the maximum head column: 8.0 m on the 21000, up to 9.5 m on the 44000, but only 4.6 m on either 12 V model.
- 4. Leave headroom. A pump working at its ceiling delivers a fraction of its rated flow.
Step three: mains or 12 V?
| Option | Flow and head | Choose it when |
|---|---|---|
| 230 V mains, 21000 to 44000 | 21,000 to 44,000 l/h, heads to 9.5 m | Standard ponds, streams and koi systems |
| 12 V low voltage, 20000 or 27000 | 19,300 or 27,000 l/h, head 4.6 m | Swimming ponds, or anywhere low voltage in the water is the priority |
The 12 V models trade head for safety. At 4.6 m they suit flat sites, not tall waterfalls.
What it costs to run, because these are the big draws
| Model | Draw | Per day at 24 h | Per year |
|---|---|---|---|
| AquaMax Eco Expert 21000 | 40 to 350 W | $0.29 to $2.52 | $105 to $920 |
| AquaMax Eco Expert 26000 | 60 to 440 W | $0.43 to $3.17 | $158 to $1,156 |
| AquaMax Eco Expert 36000 | 90 to 540 W | $0.65 to $3.89 | $237 to $1,419 |
| AquaMax Eco Expert 44000 | 140 to 700 W | $1.01 to $5.04 | $368 to $1,840 |
| 12 V models, 20000 and 27000 | 30 to 260 W | $0.22 to $1.87 | $79 to $683 |
Worked at 30c per kWh running 24 hours a day, which is our assumption rather than a manufacturer figure. Put your own tariff against the wattage and the sums are the same.
Every model here is variable speed, which is why the range is so wide. Run it hard when the pond needs it, wind it back overnight or through the cooler months. At the top of the 44000 range you are spending more on power in a year than many pumps cost to buy, so the speed control is the point, not a feature.
What to measure before you decide
- Pond volume in litres, or your filter maximum flow.
- Vertical rise from the water surface to the outlet, in metres.
- Hose run length and internal diameter. These take 38 or 50 mm.
- Whether you want to run it slower overnight, since every model here is variable speed.
- Whether low voltage matters at your site, which decides mains against 12 V.
Flow, head, then supply. If you would rather have it checked, send us the pond volume, the rise and the hose run. We will confirm the model.
See it in action
- Filmed by Oase
- Nothing loads until you press play
Cleaning an AquaMax Eco Expert
Oase UK takes an Expert apart, cleans it and puts it back together. Worth watching before your first clean.
AquaMax Eco Expert Pond Pump specifications
| 21000 | 26000 | 36000 | 44000 | 20000 / 12 V | 27000 / 12 V | |
|---|---|---|---|---|---|---|
| SKU | 39916 | 39917 | 54614 | 54615 | 55313 | 77918 |
| Maximum flow | 21,000 l/h | 26,000 l/h | 36,000 l/h | 44,000 l/h | 19,300 l/h | 27,000 l/h |
| Maximum head | 8.00 m | 8.50 m | 9.00 m | 9.50 m | 4.60 m | 4.60 m |
| Power consumption | 40 to 350 W | 60 to 440 W | 90 to 540 W | 140 to 700 W | 30 to 260 W | 30 to 260 W |
| Supply | 220 to 240 V, 50/60 Hz | 220 to 240 V, 50/60 Hz | 220 to 240 V, 50/60 Hz | 220 to 240 V, 50/60 Hz | 12 V | 12 V |
| Power cable | 10 m | 10 m | 10 m | 10 m | 8 m | 8 m |
| Pressure side | G 2 | G 2 | G 2 | G 2 | G 2 | G 2 |
| Suction side | G 2 | G 2 | G 2 ½ | G 2 ½ | G 2 | G 2 ½ |
| Hose connection | 38 / 50 mm | 38 / 50 mm | 38 / 50 mm | 38 / 50 mm | 38 / 50 mm | 38 / 50 mm |
| Solids handling | 11 mm | 11 mm | 11 mm | 11 mm | 11 mm | 11 mm |
| Dimensions (L × W × H) | 490 × 240 × 210 mm | 490 × 240 × 210 mm | 540 × 250 × 220 mm | 540 × 250 × 220 mm | 490 × 240 × 210 mm | 540 × 250 × 220 mm |
| Net weight | 11.9 kg | 12 kg | 14.9 kg | 14.9 kg | 15.5 kg | 17.0 kg |
| Installation | Submerged or dry | Submerged or dry | Submerged or dry | Submerged or dry | Submerged or dry | Submerged or dry |
| Warranty | 3 years, plus 2 on registration | 3 years, plus 2 on registration | 3 years, plus 2 on registration | 3 years, plus 2 on registration | 3 years, plus 2 on registration | 3 years, plus 2 on registration |
Choosing between mains and 12 V
Choose 230 V mains for koi ponds, gravity or drum filters and waterfalls. It gives the most flow and the most head. Choose 12 V low voltage for a swimming pond or natural pool. The trade is height: the 12 V models lift to 4.6 m, against 8.0 to 9.5 m on mains.
Frequently asked questions
How do I size the pump?
Start with your filter. A drum or gravity filter has a flow range. The pump should sit inside it. Then allow for height: every metre the water lifts to a waterfall or filter reduces the flow you actually get. Send us the filter, the lift and the pipe run. We will pick the size with you.
Mains or 12 V?
The 230 V mains models give more flow and head for koi ponds, filters and waterfalls. The 12 V models run from a low voltage supply for swimming ponds and natural pools, including saltwater. Confirm what arrives with the 12 V models when you order.
Can it run out of the water?
Yes. It can be submerged in the pond or dry installed in a pump chamber, where its quiet running suits a spot near the house.
How does the flow adjustment work?
Flow is adjusted electronically. The Seasonal Flow Control function can save up to 30% more energy by matching output to the season. The pump can also be controlled through the OASE Control app with a Garden Controller or InScenio FM-Master.
What happens if it runs dry or blocks?
Environmental Function Control, which Oase call EFC, protects the pump against running dry and blockages. It still needs a clean intake, so check the screen when you service the pond.
What will it move through?
Solids up to 11 mm, such as plant material and fish waste, pass through to the filter rather than clogging the pump.
What does the warranty cover?
Oase give 3 years, plus a further 2 years when you register the pump with Oase. You call My Acre and we handle the claim with Aquatec, the Australian distributor.
